Platform capabilities

Eight feature areas that support the full design workflow

Each feature connects into a single process from drawing import to technical report.

AI-Assisted Wall Detection

Reduce the time required to convert architectural drawings into a usable CCTV design environment.

PDF or image floor plan→ Editable wall geometry

AI-assisted wall detection converting a floor plan into editable geometry

Camera Placement and Configuration

Position cameras so their field of view matches the project requirements and physical constraints.

Camera model or sensor/lens data→ Positioned camera with FOV cone

Camera placement and configuration in the workspace

DORI and Pixel-Density Analysis

Make coverage decisions based on pixel density and standard CCTV observation criteria.

Camera resolution, sensor, and lens→ Color-coded DORI zones

Blind-Spot and Overlap Analysis

Identify gaps before installation and reduce unexpected coverage failures.

Camera positions and FOV→ Visible coverage area

Live-Map Design

Coordinate outdoor camera placement with real-world geography and boundaries.

Geographic map data→ Georeferenced camera layout

ICT and Network Planning

Keep the physical layout and network infrastructure consistent in one deliverable.

Camera positions→ Camera-switch assignments

Coverage Simulation

Find weak points in the design before they become site problems.

Camera configuration→ Path coverage traces

Professional Reports

Communicate the design clearly to clients, consultants, contractors, and reviewers.

Final camera layout→ PDF or HTML report

Workflow

From imported drawing to technical report

The features above map directly to the stages a CCTV designer follows on a real project.

Prepare

Import and calibrate

Model

Detect or draw walls

Design

Place cameras

Validate

Review coverage

Get started

Start designing for free

Eligible new users receive free access for the first 12 months.

Start Designing
